PSRV-110HD VBED Retriever

PSRV-110HD

Deep V, ground level loaded freezer spacer removal machine. Single clamping plate with a jaw opening from 110" max to 63" Min. Loading table: 50" x 50" capacity 4,000 lbs. Hydraulic lever operator controls with a manual starter mounted on the protective railing. Three year parts and labor warranty. Special Order. Made in the USA.

Request a Quote

Call 847-443-3861 to speak with our experts

Product Information

Deep V freezer spacer removal machine. Increased capacity, severe duty components & extended clamping plate range, handling loads from 63" up to 110". Best used for freezer spacer removal on double stacked loads, removal of center pallet, combining (2) pallet loads or cubing out trailer/container. Extended warranties, preventative and installation service agreements available.

Product Tour

Specifications

Model	PSRV-110HD VBED
Loading Table Size	50" x 50"
Max. Jaw Opening	110"
Min. Jaw Opening	63"
Loading Height	Ground level
Load/Unload Height	Ground level
Working Table Height	40'' Pallet Removal \| 53 1/4" Spacer Removal
Controls	Push Button
Capacity	4,000 lbs
Main Turnover Cylinders	2

System Pressure	2,000 PSI
Adjustable Clamp Pressure	1,000 PSI
Cycle Rate	30 pallets per hour
Certifications	Optional: UL Certified Panel
Speed	Stand Up 20 secs/ Lay Down 27 secs
Motor	5 HP
Pump GPM	6.6 GPM
Power Source	208/230/460/575V
Anchors	14
Finish	Orange two part epoxy paint

Warranty	3 year parts and labor. Extended warranty available.
Operating Length	223"
Operating Height	132"
Operating Width	115"
Width With Guards	94"
Shipping Class*	100
Shipping weight*	5,400 lbs
Shipping Dimensions	140" L x 96" W x 102" H
Brand	Cherry's Industrial Equipment Corp
